A more serious comparison – iPhone 7 Plus vs dSLR

For three years now, Arstechnica has been comparing images of a same scene taken with a high-end smartphone, and with two good full frame dSLRs. By the way, one of the two cameras they tested was Sony’s A7 II, which is a full frame mirrorless camera, not a dSLR, but we’ll ignore this detail . They just published the latest iteration of their tests:

http://arstechnica.com/gadgets/2016/12/mini-shootout-can-iphone-7s-bag-of-tricks-compete-with-a-real-dslr/

Just a quote: “phones long ago left “good enough” territory; images produced by a modern smartphone like the iPhone 7 Plus or Google Pixel can be flat-out excellent when the images are constructed to play to the smartphones’ strengths.” (Lee Hutchinson)

No wonder the camera maker are now preparing Full Frame or Medium Format digital cameras with 50 MegaPixel sensors. Trying to maximize the advantages of a conventional camera for the situations when the smartphone is not good enough.


Chicago - iPhone 5S
Chicago – iPhone 5S

Old lenses on new gear – manual focus lenses on mirrorless cameras

One of the most remarkable changes brought by the advent of mirrorless camera systems (micro 4/3rds, Fujifilm X and to an even larger extent Sony E and FE) is the ability to mount and effectively use almost any old lens designed originally for a 35mm camera system.

With SLR and dSLR camera systems, it was pointless to try and mount lenses designed for another system, and very often, lenses from a previous generation of the same camera system:

canon_adapt-7378
Two mount adapters: Canon FD to Fuji X, and Nikon F to Fuji X. Those Fotasy adapters are not fancy but they’re cheap and they do the job.
  • SLRs and dSLRs have optical viewfinders – the photographer needs all the light he/she can get for focusing and composing the picture, and the cameras are therefore designed to work at full aperture with aperture pre-selection – which used to require rods and springs and cams, and since the Canon EOS mount opened the way, now requires electronics. There is no simple way to emulate the pre-selection mechanism of one SLR system  with a lens designed for another one.
  • There are also physical limitations:
    • The adaptor designed as the interface between a lens of System A and a camera body of System B is more or less a cylinder with the female part of the mount of System A at one end, and the male part of System B at the other end. Such an adapter would necessarily have a depth of 5 to 15mm, which adds to the flange distance. Unfortunately, all digital single lens reflex cameras derived from 35mm SLR systems have a very similar flange distance (from 42mm for the Canon FL/FD mount up to 46.5mm for the Nikon F), and there is not enough room for an adapter (the adapted lens would sit too far from the camera’s film plane, and would not focus to infinite).

Mirrorless camera systems don’t have such limitations:

canon_adapt-7380
Canon FD to Fuji X (left) and Nikon F to Fuji X (right). The Nikon mount range distance is a bit higher than the FD’s. Therefore the adapter is thicker.
  • They have electronic viewfinders – and offer a clear and bright view of the subject even stopped down at f/16. If fact, most of the mirrorless cameras operate at stopped down aperture even with their native lenses.
  • The flange distance of mirrorless systems is much shorter (17 to 20mm for the most common systems), which leaves plenty of room (almost 30mm ) for the adaptor if you want to mount a lens designed for a SLR or DSLR system.
  • Thanks to their electronic viewfinders, mirrorless systems have multiple ways to assist the operator trying to focus manually (magnifier, zebra, focus peaking).

The use of CAD and CNC is now widespread and it’s easy and cheap to manufacture mechanical mount adapters: users of each of the big mirrorless camera systems have access to adapters for :

  • Most pre-AF era mounts for 35mm systems: (39mm and 42mm, Canon FL/FD, Konica, Nikon F, Minolta MD, Olympus OM, Leica M and R, Topcon, …)
  • Stranger or more exotic mounts (C mount, Adaptall,  Holga, medium format cameras)
canon_adapt-7370
Fuji film X-T1, Canon FD to Fuji X adapter (Fotasy), and Canon FL 55mm. The X-T1 is a pleasure to use even with old lenses.

Even if it’s physically possible, mounting recent AF/all electronics lenses is generally pointless – not only you can’t set the aperture for lack of an aperture ring, but you can’t focus the lens because modern lenses are devoid of any mechanical connection between the focusing ring and the focusing mechanism of the lens. Unless a third party vendor develops an adapter which embarks the complex software required to translate the communication protocols of a lens of Brand A into something the body of Brand B will understand.

As far as I know, it has only been attempted with some level of success between a few lenses with a Canon or Sigma mount and a few Sony bodies (the A7R II or the A6300).

Therefore, the best candidates are lenses from the manual focus era (up to 1985), and the Nikon and Pentax autofocus lenses designed before Year 2000 – they all still have aperture rings.

Even if it is possible, mounting an old manual focus lens on a mirrorless body is not necessarily the best thing to do:

  • in spite of all the focus assistance mechanisms, it’s much slower to get the focus with an adapted vintage lens than with the native autofocus lens – adapted lenses are not a good fit for mobile subjects, unless you adopt old school focusing techniques (pre-focus, wait for subject to be at right distance, and shoot)
  • Older lenses were designed for 35mm film cameras, and are unnecessarily large and heavy when mounted on M4/3rd and APS-C cameras
  • Lots of older lenses were not that good in their heyday, and become really bad if mounted on a camera with a high resolution sensor. It’s true in particular for zooms and to a lesser extent for wide angle lenses.

As a conclusion, why mount old lens on a modern mirrorless body?

  • Because you can (of course)

    Leica Summicron C (40mm f/2) mounted on Sony NEX 3 with Metabones adapter. It worked pretty well.
    Leica Summicron C (40mm f/2) mounted on a Sony NEX 3 with Metabones adapter. The Nex 3 was surprisingly easy to use with a manual lens. The Metabones adapter is really stiff, and it’s one step above the Fotasy in terms of quality. Not sure it’s worth the price, though.
  • If you already have the lens… Considering adapters sell for $20.00, it’s tempting to buy one to use your old lenses, as a stop gap until you buy a modern equivalent in the mirrorless system, or even permanently
    • All macro lenses are a very good fit because macro photography does not require to focus fast, and old macro lenses are still up to the task, when compared to their modern equivalents
  • If you want to experience really exceptional glass
    • Canon FD Aspherical or “L” lenses (50mm f/1.2, 85mm f/1.2) for instance, or some of the gems that Leica, Minolta, Nikon, Pentax and others have produced in the past…
  • If the modern equivalent does not exist…
    • a 55mm f/1.2 lens – it doesn’t exist for the Sony E/FE mount
    • a teleobjective with Defocus Control – only Nikon has them
    • a tilt and shift lens (only Canon and Nikon have them)
  • or exists but is crazy expensive
    • can an amateur afford the new Sony 85 f/1.4 FE GM?

As a result, old lenses of good reputation hold their value extremely well. Some of the  Canon and Nikon lenses I mentioned above sell for more than $700.00 on eBay.

Jules - Fujifilm X-T1 - Canon FL 55mm f/1.2
Jules – Fujifilm X-T1 – Canon FL 55mm f/1.2


5 Years later

I started this blog in 2009. And wrote most of the entries between September 2009 and Sept 2010.

Between 2012 and 2015, I did not do much in terms of photography. I did not use my film cameras anymore – too cumbersome – forgot about my DSLR – too large, too heavy. I bought a Nikon V1 mirrorless camera – and got rid of it rapidly, very disappointed by the image quality. In fact, I spent the last four years taking pictures with my iPhone.

At the end of last year, while travelling for business, the desire to take better pictures than what an iPhone could do came back. I bought a $200.00 point and shoot Sony camera, and was so impressed by its technical abilities that I … returned it immediately to buy a second-hand Sony mirrorless camera – a rather scruffy NEX 6 with the tiny 16-50mm Power Zoom. I liked the NEX 6 so much that I decided to invest seriously in the Sony system. The week after I bought it, I returned the NEX to the vendor, and upgraded to a clean and shiny A6000 with a Sony-Zeiss prime lens. In the process, I sold my old Nikon DSLR and a few Nikon F mount lenses.

Old lens - new life
Atlanta- Centennial Park – Shot in June 2016 with a Sony A6000 and a Nikon 24mm f/2.8 AF (non D) lens

Unfortunately, I could never adjust to the ergonomics and idiosyncrasies of the A6000 (it’s made by engineers specialized in electronics under the guidance of marketing people, not by photographers). The sensor is really great, but I did not like the APS-C Sony zooms – too much distortion with the cheap ones, fear of quality control issues with the expensive ones. I did not like the cost of their prime lenses (the real good ones are very expensive), and had doubts about the commitment of Sony to its APS-C line of products – it’s all about the A7 and its full frame sensor nowadays. Looking for something totally different, I bought a Fujifilm X100. I liked it. A camera designed by photographers for photographers. Comforted by the experience, I decided to bite the bullet, and sold all my Sony equipment to pay for a second hand X-T1 and its 18-55 zoom. I positively love my Fujifilm cameras, and I should keep them for a long time.

With my passion for photography re-ignited, I’m re-activating this blog.

In the first entries, I’ll focus on what changed in the world of photography in the last 5 years – the rise of the smartphone, the disappearance of color film as a mass consumption product, and the parallel rebirth of true black and white and instant film à la Polaroid. Then I will go back to what constitutes the core of this blog – giving old gear a new life.
